Description
All Frontier models feature Hawke’s H7 optics, offering stunning high definition viewing with incredible color control and phase correction. High performance lens coatings and Dielectric Coated prisms ensure the highest level of light transmission.
The Frontier APO offers extreme clarity, flat field vision along with excellent chromatic aberration control for a stunning wide angle image.
APO models benefit from Extra-low Dispersion glass for controlled chromatic aberration and the elimination of color fringing.
Features
- APO Lenses
- Extra-low Dispersion (ED) glass
- Dielectric Coatings
- High resolution phase corrected BAK-4 roof prisms
- Water repellent lens coatings
- Magnesium alloy chassis
- Focus from 2m
- Replaceable twist-up eye cups with position stops
- Stay-on lens covers
Specs
Specs Highlights:
Magnification
10x
Objective Lens
42mm
Field of View (°)
7.1
Eye Relief
0.7in, 17mm
Exit Pupil
0.17″, 4.2mm
Field of View
372ft @1000yds, 124m @1000m
Height
5.6″, 141mm
Weight
26.1oz, 740g
| Magnification | 10x |
| Objective Lens | 42mm |
| Lens Coating | Wide Band, Anti-reflection, Fully Multi-Coated Lenses with Water Repellent Coating |
| Colour | Green |
| Optical System | System H7 |
| Field of View (°) | 7.1 |
| Eye Relief | 0.7in, 17mm |
| Exit Pupil | 0.17″, 4.2mm |
| Field of View | 372ft @1000yds, 124m @1000m |
| Apparent Field of View (°) | 71 |
| Interpupillary Distance | 2.3 - 3.1″, 58 - 78mm |
| Close Focus | 6.6ft, 2m |
| Prism Type | Roof |
| Prism Glass | BAK 4 |
| Eye Cups | Twist-Up (Replaceable) |
| Eyecup ⌀ | 1.8i, 46mm |
| Diopter Type | Right Eye |
| Tripod Mounting Thread | Yes (¼" - 20 UNC) |
| Height | 5.6″, 141mm |
| Width | 4.3 - 5.1″, 109 - 130mm |
| Weight | 26.1oz, 740g |
